To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Carlo Gavazzi |
| Manufacturer Product Number | EI5510NPAP-1 |
| Description | Inductive Sensor; 10 mm; NPN; NO + NC; 10–32 V DC; Plug; Rectangular |
| Datasheet | Download Datasheet |
The Carlo Gavazzi EI5510NPAP-1 is a rectangular flush inductive proximity sensor with a 10 mm sensing range, NPN NO + NC output and a 10–32 V DC supply.
Output current 200 mA. Power-on delay ≤ 50 ms. Indicator: yellow LED. It has a plug and a polycarbonate, grey housing. IP 67; operating temperature -25 to +70 °C (storage -30…+80). Approvals: UL, CSA, CE.
| Category | |
| Manufacturer | Carlo Gavazzi |
| Model | EI5510 |
| Body Style | Rectangular |
| Sensing Range | 10 mm |
| Sensing Face | Flush |
| Output Type | NPN |
| Output Function | NO + NC |
| Supply Voltage | 10–32 V DC |
| Supply Current | ≤ 7 mA |
| Load Current | 200 mA |
| Voltage Drop | ≤ 2 V DC at max. load |
| Repeatability | ≤ 5% |
| Short Circuit Protection | Yes (reverse polarity, short-circuit) |
| Status Indicator | Yellow LED |
| Connection | Plug |
| Mounting Type | Flush mounting in metal, two M3.5 screws |
| Housing Material | Polycarbonate, grey |
| Protection Category | IP 67 |
| Operating Temperature (°C) | -25…+70 (storage -30…+80) |
| Dimensions | 35 x 55 x 15 mm |
| Approvals | UL, CSA, CE |
| Response Time | Power-on delay ≤ 50 ms |
