Product Description
|
| Product Information | Resources |
|
|
RoHS Compliant| Specifications |
| Product Attribute | Attribute Value |
| Circuit | DPDT |
| Contact Timing | Not Specified |
| Switch Function | On-Off-On |
| Current Rating (Amps) | 0.4VA (AC/DC) |
| Voltage Rating - DC | 20 V |
| Voltage Rating - AC | 20 V |
| Actuator Type | Standard |
| Actuator Length | 3.24mm |
| Contact Material | Copper Alloy |
| Contact Finish | Gold |
| Mounting Type | Through Hole, Right Angle, Vertical |
| Termination Style | PC Pin |
| Operating Temperature | -40°C ~ 85°C |
| Series Features |
| 1000 Series Slide Switch |
| Series Description: The 1000 Series is a UL Approved, through-hole miniature slide switch with a choice of SPDT or DPDT poles. This panel mount switch features functions including: On-None-On, On-None-(On) and On-Off-On. Actuator lengths range from 3.6mm up to 9.4mm with termination options of solder lug, standard PC pin, quick connect, horizontal mount right angle PC pin, vertical mount right angle PC pin, or PC pin with support bracket. The 1000 Series mini slide switch is offered with or without mounting ears and housing of steel and nylon. Contact us to order your custom right angle switch today. |
|
