To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Adam Tech |
| Manufacturer Product Number | USB-B-S-VT-30 |
| Description | USB Connector; USB-B (USB TYPE-B); Receptacle; Through Hole; 1 Port; Solder |
| Datasheet | Download Datasheet |
| Catalog | Download Catalog |
The Adam Tech USB-B-S-VT-30 is a USB Type-B receptacle. USB standard: USB 2.0 (480Mb/s). Contacts: 4. Mounting: through hole; vertical. Shielded.
Shell: Copper Alloy, nickel plated.
Contacts: phosphor bronze, 30u" gold flash over nickel underplate on contact area, tin over copper underplate on PCB tails. Insulator: PBT, Glass filled, rated UL 94V-0; color: black.
Current rating: 1.5 A. Voltage rating: 30 VAC. Operating temperature -20°C ~ 60°C.
Approvals: UL Recognized File No. E224053; USB-IF Implementers Forum.
| Category | |
| Manufacturer | Adam Tech |
| USB Type | USB-B (USB TYPE-B) |
| Mounting Type | Through Hole |
| Gender | Receptacle |
| Termination | Solder |
| Number of Ports | 1 Port |
| Number of Contacts | 4 |
| Shielding | Shielded |
| Mounting Feature | Vertical |
| Current Rating (A) | 1.5 A |
| Operating Temperature | -20°C ~ 60°C |
| Voltage Rating | 30 VAC |
| USB Standard | USB 2.0 (480Mb/s) |
| Insulator Material | PBT, Glass filled, rated UL 94V-0; color: black |
| Contact Material | Phosphor Bronze |
| Shell Material | Copper Alloy, nickel plated |
| Plating Detail | 30u" Gold flash over Nickel underplate on contact area, Tin over Copper underplate on PCB tails |
| Approvals | UL Recognized File No. E224053; USB-IF Implementers Forum |
