To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Adam Tech |
| Manufacturer Product Number | PH2-3F-08-MVF-3345-C1 |
| Description | Spring Loaded Connector; 8-pos; Surface Mount; 4.5 mm; .100" [2.54mm] |
| Datasheet | Download Datasheet |
| Catalog | Download Catalog |
| Brochure | Download Brochure |
The Adam Tech PH2-3F-08-MVF-3345-C1 is a 8-position dual-row spring-loaded (pogo pin) connector, male, .100 in (2.54mm) pitch. Mounting: vertical, surface mount. Initial height: 4.5 mm (3.30 mm tube). Full stroke: 1.40mm. Spring force: 90±20gf @ 1.0mm working stroke.
Contacts: Copper Alloy. Plating: Gold flash over Nickel underplate overall. Spring: Stainless Steel. Insulator: PA46, rated UL 94V-0.
Current rating: 1 A max. Voltage rating: 12 V. Operating temperature: -30°C ~ 85°C. Life: 10,000 cycles.
| Category | |
| Manufacturer | Adam Tech |
| Product Type | Spring Loaded Connector (Pogo Pin) |
| Gender | Male |
| Number of Positions | 8 |
| Number of Rows | 2 |
| Pitch | .100" [2.54mm] |
| Orientation | Vertical |
| Mounting Type | Surface Mount |
| Termination | Surface Mount |
| Current Rating | 1 A max |
| Voltage Rating | 12 V |
| Initial Height | 4.5 mm |
| Tube Length | 3.30 mm |
| Full Stroke | 1.40mm |
| Spring Force | 90±20gf @ 1.0mm working stroke |
| Color | Black |
| Contact Material | Copper Alloy |
| Plating Detail | Gold flash over Nickel underplate overall |
| Spring Material | Stainless Steel |
| Insulator Material | PA46, rated UL 94V-0 |
| Operating Temperature | -30°C ~ 85°C |
| Mating Cycles | 10000 |
