To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Adam Tech |
| Manufacturer Product Number | MTD-A-03-C-1 |
| Description | IDC Connector; 3-position; .100" [2.54mm]; Feed Through; 22-28 AWG; 3 A max. |
| Datasheet | Download Datasheet |
The Adam Tech MTD-A-03-C-1 is a 3-position, 2.54 mm (.100 in) pitch IDC wire-to-board connector, feed through style. Discrete wires press into insulation-displacement contacts, with no stripping or crimping. Wire size: 22-28 AWG. Body length: short.
Contacts: phosphor bronze, tin over copper underplate overall. Insulator: Nylon 66, rated UL 94V-2.
Current rating: 3 A max. Voltage rating: 250V AC/DC max. Operating temperature -40 °C to +105 °C.
Approvals: UL Recognized File no. E224053.
| Category | |
| Manufacturer | Adam Tech |
