To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Adam Tech |
| Manufacturer Product Number | DB25-SQ-R3 |
| Description | D-Sub Connector; D-Sub; 25-pos; Receptacle, Female Sockets; Through Hole, Right Angle |
| Datasheet | Download Datasheet |
| Catalog | Download Catalog |
The Adam Tech DB25-SQ-R3 is a 25-position D-Sub connector, receptacle, female sockets, shell size B (DB-25). Termination: solder. Mounting: through hole, right angle. Footprint / port spacing: .590". Mounting hardware: forked boardlocks on full flange; #4-40 fixed jackscrews.
Insulator: PBT, glass reinforced, rated UL94V-0; color: black. Contacts: copper alloy, 5 uin gold nom. to MIL-G-45204, type II, grade C on contact area over 50 uin nickel underplate to QQ-N-290, class 2, grade C, gold flash on tails.
Current rating: 3 A. Operating temperature -55 °C to +105 °C.
| Category | |
| Manufacturer | Adam Tech |
| Gender | Receptacle, Female Sockets |
| Connector Style | D-Sub |
| Number of Positions | 25 |
| Mounting Type | Through Hole, Right Angle |
| Flange Feature | Forked boardlocks on full flange; #4-40 fixed jackscrews |
| Termination | Solder |
| Shell Size, Connector Layout | B (DB-25) |
| Current Rating (A) | 3 A. |
| Backset Spacing | .590" |
| Insulator Material | PBT, glass reinforced, rated UL94V-0; color: black |
| Contact Material | Copper alloy |
| Plating Detail | 5 uin gold nom. to MIL-G-45204, Type II, Grade C on contact area over 50 uin nickel underplate to QQ-N-290, Class 2, Grade C, gold flash on tails. |
| Operating Temperature | -55...+105 |
