To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Adam Tech |
| Manufacturer Product Number | D7W2-PLP-X-2-BL-A |
| Description | D-Sub Connector; 7 total (2 coax / power)-pos; Plug, Male Pins |
| Datasheet | Download Datasheet |
| Catalog | Download Catalog |
The Adam Tech D7W2-PLP-X-2-BL-A is a combination D-Sub connector (signal plus coax / power contacts), plug, male pins. Positions: 7 total (2 coax / power). Termination: solder. Mounting: through hole, right angle. Mounting hardware: riveted board locks. Options: 75 ohm.
Insulator: Thermoplastic, Glass filled, rated UL 94V-0; color: black. Contacts: brass, gold flash over nickel underplate overall.
Current rating: 10 - 40 A (Power Contact) 5 A (Signal Contact). Operating temperature -55 °C to +125 °C.
Current by wire size, from the Adam Tech drawing: ADAM P/N | Current Rating | Dim øA | Dim øB; D7W2-PLP-6-2-BL-A | 40 Amps | ø.148 [3.75] | ø.165 [4.20]; D7W2-PLP-5-2-BL-A | 30 Amps | ø.126 [3.20] | ø.144 [3.65]; D7W2-PLP-4-2-BL-A | 20 Amps | ø.110 [2.80] | ø.129 [3.28]; D7W2-PLP-3-2-BL-A | 10 Amps | ø.067 [1.70] | ø.087 [2.20].
| Category | |
| Manufacturer | Adam Tech |
| Gender | Plug, Male Pins |
| Connector Style | D-Sub, Combination (signal + coax / power) |
| Number of Positions | 7 total (2 coax / power) |
| Mounting Type | Through Hole, Right Angle |
| Contact Type | Signal and power contacts |
| Flange Feature | Riveted Board Locks |
| Termination | Solder |
| Current Rating (A) | 10 - 40 A (Power Contact) 5 A (Signal Contact) |
| Features | 75 Ohm |
| Insulator Material | Thermoplastic, Glass filled, rated UL 94V-0; color: black |
| Contact Material | Brass |
| Plating Detail | Gold flash over Nickel underplate overall |
| Operating Temperature | -55...+125 |
| Current by Wire Size | ADAM P/N | Current Rating | Dim øA | Dim øB; D7W2-PLP-6-2-BL-A | 40 Amps | ø.148 [3.75] | ø.165 [4.20]; D7W2-PLP-5-2-BL-A | 30 Amps | ø.126 [3.20] | ø.144 [3.65]; D7W2-PLP-4-2-BL-A | 20 Amps | ø.110 [2.80] | ø.129 [3.28]; D7W2-PLP-3-2-BL-A | 10 Amps |
