To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Adam Tech |
| Manufacturer Product Number | LHA-06-GS-BG-15 |
| Description | Board Connector; 6-position; .100" [2.54mm]; Vertical; Through Hole; Gold; 2.5 A |
| Datasheet | Download Datasheet |
| Catalog | Download Catalog |
The Adam Tech LHA-06-GS-BG-15 is a 6-position, 2.54 mm (.100 in) pitch shrouded board header with male pins, vertical through-hole to the PCB.
Contacts: brass, gold flash plated, 15u" gold over nickel underplate overall. Insulator: Nylon 66, rated UL 94V-2; color: beige.
Current rating: 2.5 A. Voltage rating: 250 VAC. Operating temperature -25 °C to +85 °C.
Approvals: UL Recognized File no. E224053.
| Category | |
| Manufacturer | Adam Tech |
| Connector Type | Header, shrouded |
| Contact Type | Male Pin |
| Number of Positions | 6 |
| Pitch | .100" [2.54mm] |
| Orientation | Vertical |
| Mounting Type | Through Hole |
| Contact Finish | Gold |
| Plating Detail | 15u" Gold over Nickel underplate overall |
| Contact Material | Brass, Gold flash plated |
| Insulator Material | Nylon 66, rated UL 94V-2; color: beige |
| Current Rating | 2.5 A |
| Voltage Rating | 250 VAC |
| Operating Temperature | -25...+85 |
| Approvals | UL Recognized File no. E224053 |
