To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Adam Tech |
| Manufacturer Product Number | DML-1-06-A-H-T-A |
| Description | Board Connector; 6-position; .118" [3.00mm]; Right Angle; Through Hole; Tin; 5 A |
| Datasheet | Download Datasheet |
| Catalog | Download Catalog |
The Adam Tech DML-1-06-A-H-T-A is a 6-position, single-row, 3 mm (.118 in) pitch shrouded board header with male pins, right angle through-hole to the PCB.
Contacts: brass, tin plated. Insulator: LCP, rated UL 94V-0; color: black.
Current rating: 5 A. Voltage rating: 250 VAC. Operating temperature -40 °C to +105 °C.
Approvals: UL Recognized File no. E224053.
| Category | |
| Manufacturer | Adam Tech |
| Connector Type | Header, shrouded |
| Contact Type | Male Pin |
| Number of Positions | 6 |
| Number of Rows | 1 |
| Pitch | .118" [3.00mm] |
| Orientation | Right Angle |
| Mounting Type | Through Hole |
| Contact Finish | Tin |
| Contact Material | Brass, Tin plated |
| Insulator Material | LCP, rated UL 94V-0; color: black |
| Current Rating | 5 A |
| Voltage Rating | 250 VAC |
| Operating Temperature | -40...+105 |
| Approvals | UL Recognized File no. E224053 |
