| Manufacturer | Adam Tech |
| Manufacturer Product Number | 2SH-H-02-TS-YW |
| Description | Board Connector; 2-position; .079" [2.00mm]; Vertical; Through Hole; Tin; 3A AC/DC |
| Datasheet | Download Datasheet |
The Adam Tech 2SH-H-02-TS-YW is a 2-position, single-row, 2 mm (.079 in) pitch shrouded board header with male pins, vertical through-hole to the PCB. It is the board half of Adam Tech's 2SH wire-to-board system: it mates with the 2CH crimp wire housing of the same pitch, position count and body style. Adam Tech body style H.
Contacts: brass, tin over copper underplate overall. Insulator: PBT, rated UL 94V-0; color: white.
Current rating: 3A AC/DC. Voltage rating: 100V AC max. Operating temperature -25 °C to +85 °C.
Approvals: UL Recognized File no. E224053.
