To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Adam Tech |
| Manufacturer Product Number | 125SH-B-12-TS |
| Description | Board Connector; 12-position; .049" [1.25mm]; Vertical; Through Hole; Tin; 1 A max |
| Datasheet | Download Datasheet |
| Catalog | Download Catalog |
The Adam Tech 125SH-B-12-TS is a 12-position, single-row, 1.25 mm (.049 in) pitch shrouded board header with male pins, vertical through-hole to the PCB. It is the board half of Adam Tech's 125SH wire-to-board system: it mates with the 125CH crimp wire housing of the same pitch, position count and body style. Adam Tech body style B.
Contacts: brass, tin over nickel underplate overall. Insulator: Nylon 66, rated UL 94V-0; color: natural.
Current rating: 1 A max. Voltage rating: 125 VAC max. Operating temperature -40 °C to +85 °C.
Approvals: UL Recognized File no. E224053.
| Category | |
| Manufacturer | Adam Tech |
| Connector Type | Header, shrouded |
| Contact Type | Male Pin |
| Number of Positions | 12 |
| Number of Rows | 1 |
| Pitch | .049" [1.25mm] |
| Orientation | Vertical |
| Mounting Type | Through Hole |
| Body Style | B |
| Contact Finish | Tin |
| Plating Detail | Tin over Nickel underplate overall |
| Contact Material | Brass |
| Insulator Material | Nylon 66, rated UL 94V-0; color: natural |
| Current Rating | 1 A max |
| Voltage Rating | 125 VAC max |
| Operating Temperature | -40...+85 |
| Approvals | UL Recognized File no. E224053 |
