To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Adam Tech |
| Manufacturer Product Number | 125SH-B-04-TR |
| Description | Board Connector; 4-position; .049" [1.25mm]; Right Angle; Through Hole; Tin; 1A AC, DC |
| Datasheet | Download Datasheet |
The Adam Tech 125SH-B-04-TR is a 4-position, single-row, 1.25 mm (.049 in) pitch shrouded board header with male pins, right angle through-hole to the PCB. It is the board half of Adam Tech's 125SH wire-to-board system: it mates with the 125CH crimp wire housing of the same pitch, position count and body style. Adam Tech body style B.
Contacts: copper alloy, tin over nickel underplate overall. Insulator: Hi-temp thermoplastic, rated UL 94V-0; color: beige.
Current rating: 1A AC, DC. Voltage rating: 125V AC, DC. Operating temperature -25 °C to +85 °C.
Approvals: UL Recognized File no. E224053.
