Adam Tech PH2-08-TA-SMT-PP-T/R

Manufacturer	Adam Tech
Manufacturer Product Number	PH2-08-TA-SMT-PP-T/R
Description	Board Connector; 8-position; .100" [2.54mm]; Vertical; Surface Mount; Tin; 3 A max
Datasheet	Download Datasheet

Product Description

The Adam Tech PH2-08-TA-SMT-PP-T/R is a 8-position, dual-row, 2.54 mm (.100 in) pitch pin header with male pins, vertical surface-mount.

Contacts: brass, tin over copper underplate overall. Insulator: Hi-temp thermoplastic, rated UL 94V-0; color: black.

Current rating: 3 A max. Voltage rating: 250V AC max. Operating temperature -40 °C to +105 °C.

Pick and place cap. Approvals: UL Recognized File no. E224053.
