To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | Adam Tech |
| Manufacturer Product Number | 2BHR-16-VSGA |
| Description | Board Connector; 16-position; .079" [2.00mm]; Vertical; Through Hole; Selective Gold |
| Datasheet | Download Datasheet |
| Catalog | Download Catalog |
The Adam Tech 2BHR-16-VSGA is a 16-position, dual-row, 2 mm (.079 in) pitch shrouded board header with male pins, vertical through-hole to the PCB.
Contacts: brass, gold flash over nickel underplate on mating area, tin over copper underplate on tails. Insulator: PBT, glass reinforced, rated UL 94V-0; color: black.
Current rating: 1 A max. Voltage rating: 250 VAC max. Operating temperature -55 °C to +105 °C.
Approvals: UL Recognized File no. E224053.
| Category | |
| Manufacturer | Adam Tech |
| Connector Type | Header, shrouded |
| Contact Type | Male Pin |
| Number of Positions | 16 |
| Number of Rows | 2 |
| Pitch | .079" [2.00mm] |
| Orientation | Vertical |
| Mounting Type | Through Hole |
| Contact Finish | Selective Gold |
| Plating Detail | Gold Flash over Nickel underplate on mating area, Tin over Copper underplate on tails |
| Contact Material | Brass |
| Insulator Material | PBT, glass reinforced, rated UL 94V-0; color: black |
| Current Rating | 1 A max |
| Voltage Rating | 250 VAC max |
| Operating Temperature | -55...+105 |
| Approvals | UL Recognized File no. E224053 |
