| Manufacturer | ATC Diversified |
| Manufacturer Product Number | TDG-120-AKA-010-600 |
| Description | Time Delay Relay; 0.1...10 s; Onboard knob; 6...600 s; Repeat Cycle (On 1st) |
| Datasheet | Download Datasheet |
The ATC Diversified TDG-120-AKA-010-600 is a recycling (ON time first) timer for 120 V AC/DC, with isolated DPDT relay contacts rated 10 A resistive at 250 V AC or 24 V DC. The ON time (T1) is adjustable from 0.1 to 10 seconds and the OFF time (T2) from 6 to 600 seconds with its onboard knob.
Upon application of supply voltage the relay energizes for the ON time, then de-energizes for the OFF time, and repeats until supply voltage is removed.
Output: 2C DPDT relay, 10 A resistive at 250 V AC or 24 V DC; 211 VA inductive at 120 V AC. It has no LED indicator. Repeat accuracy: 1% maximum, no first cycle effect. Setting accuracy: Maximum setting ±10%, minimum setting +0%/-20%. Supply tolerance: ±10% of nominal; 50/60 Hz. Power: 3 W. Life: 10,000,000 operations mechanical, 100,000 electrical.
It plugs into an 8 pin octal socket (RB-08 or PF083A). It operates from 0 to +55 °C and stores from -45 to +85 °C. Approvals: UL Recognized (E55826).
| Category | |
| Manufacturer | ATC Diversified |
| Model | TDG |
