| Manufacturer | ATC Diversified |
| Manufacturer Product Number | TDC-120-AKA-300 |
| Description | TDR; 3...300 s; Knob Adj; On Delay; 120V AC/DC; 8 Pin (Octal); 2C DPDT |
| Datasheet | Download Datasheet |
The ATC Diversified TDC-120-AKA-300 is a delay-on-make (on-delay) timer for 120 V AC/DC, with isolated DPDT relay contacts rated 10 A resistive at 250 V AC or 24 V DC. Its delay is adjustable from 3 to 300 seconds with its onboard knob.
Upon application of supply voltage the delay begins; at the end of the delay the output relay energizes and stays energized until supply voltage is removed, which resets the timer.
Output: 2C DPDT relay, 10 A resistive at 250 V AC or 24 V DC; 211 VA inductive at 120 V AC. It has no LED indicator. Repeat accuracy: 1% maximum, no first cycle effect. Setting accuracy: Maximum setting ±10%, minimum setting +0%/-20%. Supply tolerance: ±10% of nominal; 50/60 Hz. Power: 3 W. Life: 10,000,000 operations mechanical, 100,000 electrical.
It plugs into an 8 pin octal socket (RB-08 or PF083A). It operates from 0 to +55 °C and stores from -45 to +85 °C. Approvals: UL Recognized (E55826).
| Category | |
| Manufacturer | ATC Diversified |
| Model | TDC |
| Output Technology | Electromechanical Relay |
| Timing Function | On Delay |
| Delay Time | 3...300 s |
| Timing Adjustment Method | Onboard knob |
| Timing Initiate Method | Input Voltage |
| Status Indicator | None |
| Contact Configuration | 2C DPDT |
| Output Rating | 10 A resistive at 250 V AC or 24 V DC; 211 VA inductive at 120 V AC |
| Input Voltage | 120V AC/DC |
| Termination Style | Plug In, 8 Pin (Octal) |
| Mounting Type | Socketable |
| Socket Family | 8 Pin Octal |
| Required Socket | RB-08 or PF083A |
| Operating Temperature | 0...+55 °C (-45...+85 °C) |
| Approvals | UL Recognized (E55826) |
| Setting Accuracy (%) | Maximum setting ±10%, minimum setting +0%/-20% |
| Repeatability (%) | 1% maximum, no first cycle effect |
| Mechanical Life | 10,000,000 cycles (100,000 cycles) |
| Input Operating Range | ±10% of nominal; 50/60 Hz |
| Rated Power | 3 W |
