To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | ATC Diversified |
| Manufacturer Product Number | TBU-120-AAA |
| Description | TDR; 0.1...102.3 s; DIP; Multi-Function; 120V AC/DC; 11 Pin (Octal); 1C SPDT |
| Datasheet | Download Datasheet |
The ATC Diversified TBU-120-AAA is a digital multi-function timer for 120 V AC/DC, with isolated SPDT relay contacts rated 10 A resistive at 250 V AC or 24 V DC. Its delay is adjustable from 0.1 to 102.3 seconds in 0.1 s steps with DIP switches.
Output: 1C SPDT relay, 10 A resistive at 250 V AC or 24 V DC. Indicator: LED on when the relay is energized. Repeat accuracy: ±0.1% or ±8.3 ms, whichever is greater. Setting accuracy: ±2% or ±50 ms, whichever is greater. Supply tolerance: ±10% of nominal; 50/60 Hz. Power: 3 VA. Life: 10,000,000 operations mechanical, 100,000 electrical.
It plugs into an 11 pin octal socket (RB-11 or PF113A). It operates from 0 to +55 °C and stores from -45 to +85 °C. Approvals: cULus (E55826), CSA.
| Category | |
| Manufacturer | ATC Diversified |
| Model | TBU |
