To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | ATC Diversified |
| Manufacturer Product Number | 3-7685AR04F12SX |
| Description | Photoelectric Sensor; Polarized retroreflective; 12 ft (3.5 m) |
| Datasheet | Download Datasheet |
The ATC Diversified 3-7685AR04F12SX is a polarized retroreflective photoelectric sensor, a self-contained rectangular sensor with its own mounting bracket, with a dual FET (solid state), short-circuit protected output and a range of 12 ft (3.5 m). It sees the beam bounced back from the reflector supplied with it and switches when an object breaks it.
Light source: visible red, polarized. Smallest target: 2.0 in (5.1 cm). Output rating: 100 mA. Response: <3 ms. Switching rate: 166 Hz. Mode: light-on / dark-on. Supply: 10-30 V DC or 10-135 V AC. Current draw: 45 mA. Indicator: red LED. Housing: self-contained rectangular, non-metallic. Included: 2 in square reflector; mounting bracket and hardware. Enclosure: NEMA 4. It operates from -25 to +55 °C.
| Category | |
| Manufacturer | ATC Diversified |
