To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | ATC Diversified |
| Manufacturer Product Number | 3-7684AD04F22RX |
| Description | Photoelectric Sensor; Diffuse (long range); 18 in (0.5 m); SPDT relay |
| Datasheet | Download Datasheet |
The ATC Diversified 3-7684AD04F22RX is a diffuse photoelectric sensor, a self-contained rectangular sensor with its own mounting bracket, with a SPDT relay output and a range of 18 in (0.5 m). It sees light reflected straight back off the target, so no reflector is needed.
Light source: infrared. Smallest target: 0.5 in (1.25 cm). Output rating: 1.0 A at 30 V DC; 0.5 A at 120 V AC. Response: <5 ms. Switching rate: 100 Hz. Mode: light-on / dark-on. Supply: 10-30 V DC or 10-135 V AC. Current draw: 45 mA. Indicator: red LED. Housing: self-contained rectangular, non-metallic. Included: mounting bracket and hardware. Enclosure: NEMA 4. It operates from -25 to +55 °C.
