To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | ATC Diversified |
| Manufacturer Product Number | SLJ-380-ALE |
| Description | Phase Monitor Relay; 3-Phase; (350...440)V AC; 2C DPDT |
| Datasheet | Download Datasheet |
The ATC Diversified SLJ-380-ALE is a 3-phase monitor with delay on make for 350-440 V AC systems. It drops its output relay out on phase loss, phase reversal and undervoltage, with a delay-on-make timer and resets once the fault clears.
Trip points: undervoltage 290-365 V AC (one phase low); 315-396 V AC (all three phases low). Adjustment: tracks the operating-voltage setting (one phase below 83% or all three below 90%); picks up 1 V above drop-out. Trip delay: phase loss / reversal 2 s; undervoltage 2 s. Restart: 0.2-8 min adjustable (delay on make). Reset: automatic upon correction of the fault.
Output: 2C DPDT, 3 A resistive at 600 V AC; 360 VA inductive. Mounting: surface mount (#8 screws), screw terminals. Indicator: Two LEDs: green when all conditions are normal, red when the relay is energized. It operates from 0 to +55 °C and stores from -45 to +85 °C.
| Category | |
| Manufacturer | ATC Diversified |
| Model | SLJ |
| Monitoring Function | Phase Loss, Phase Reversal and Undervoltage, with a delay-on-make timer |
| Number of Phases | 3-Phase |
| Input Voltage | (350...440)V AC |
| Undervoltage Trip Range | 290-365V AC (one phase low); 315-396V AC (all three phases low) |
| Undervoltage Trip Adjustment | Tracks the operating-voltage setting (one phase below 83% or all three below 90%); picks up 1 V above drop-out |
| Restart Delay (s) | 0.2...8 min adjustable (delay on make) |
| Trip Delay - Phase Loss and Reversal (ms) | 2 s |
| Trip Delay - Undervoltage (s) | 2 s |
| Reset Method | Automatic upon correction of the fault |
| Status Indicator | Two LEDs: green when all conditions are normal, red when the relay is energized |
| Contact Configuration | 2C DPDT |
| Output Rating | 3 A resistive at 600 V AC; 360 VA inductive |
| Number of Poles | 2 |
| Mounting Type | Surface Mount - #8 screws |
| Termination Style | Screw Terminal |
| Operating Temperature (Storage) | 0...+55 °C (-45...+85 °C) |
