To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | ATC Diversified |
| Manufacturer Product Number | SLD-230-ASA |
| Description | Phase Monitor Relay; 3-Phase; 208/240V AC; 185...230 V AC; 1C SPDT |
| Datasheet | Download Datasheet |
The ATC Diversified SLD-230-ASA is a 3-phase monitor for 208/240 V AC systems. It drops its output relay out on phase loss, phase reversal, phase unbalance and undervoltage and resets once the fault clears.
Trip points: undervoltage 185-230 V AC; unbalance adjustable from 2 to 10% unbalance. Adjustment: adjustable. Trip delay: phase loss / reversal 100 ms; undervoltage 0.1-20 s adjustable; unbalance 100 ms. Restart: 30 ms. Reset: automatic upon correction of the fault.
Output: 1C SPDT, 10 A resistive at 240 V AC; 1/2 HP at 240 V AC. Mounting: plug-in, on an 8-pin octal (RB-08 or OT-08 socket) base. Indicator: LED, glows when all conditions are normal. Approvals: UL (E55826). It operates from 0 to +55 °C and stores from -45 to +85 °C.
| Category | |
| Manufacturer | ATC Diversified |
| Model | SLD |
| Monitoring Function | Phase Loss, Phase Reversal, Phase Unbalance and Undervoltage |
| Number of Phases | 3-Phase |
| Input Voltage | 208/240V AC |
| Undervoltage Trip Range | 185...230 V AC |
| Undervoltage Trip Adjustment | Adjustable |
| Phase Unbalance Trip | Adjustable from 2 to 10% unbalance |
| Restart Delay (s) | 30 ms |
| Trip Delay - Phase Loss and Reversal (ms) | 100 ms |
| Trip Delay - Undervoltage (s) | 0.1...20 s adjustable |
| Trip Delay - Unbalance | 100 ms |
| Reset Method | Automatic upon correction of the fault |
| Status Indicator | LED, glows when all conditions are normal |
| Contact Configuration | 1C SPDT |
| Output Rating | 10 A resistive at 240 V AC; 1/2 HP at 240 V AC |
| Number of Poles | 1 |
| Mounting Type | Socketable |
| Termination Style | Plug In |
| Socket Family | 8 Pin Octal (RB-08 or OT-08 socket) |
| Operating Temperature (Storage) | 0...+55 °C (-45...+85 °C) |
| Approvals | UL (E55826) |
