To ensure accuracy, please note that images may be representative. Refer to the product data sheet for detailed specifications.
| Manufacturer | ATC Diversified |
| Manufacturer Product Number | OVL32B1 |
| Description | Overload Relay; 22 - 32 A; Class 10; OVL-B1 |
| Datasheet | Download Datasheet |
The ATC Diversified OVL32B1 is an overload relay with a 22 - 32 A setting range. It mounts directly on an ATC CON Series contactor and trips the contactor's coil circuit on a motor overload (Trip Class 10) or a lost phase; the setting dial matches it to the motor's full-load current.
Relay: bimetallic (thermal), phase-loss sensitive. Fits: ATC CON Series contactors S9, S12, S18, S25, S32, S40 (direct mount). Reset: manual or automatic (selectable); test function and stop button. Voltage: 600 V AC (UL/CSA); 690 V AC (IEC). Short circuit: 5 kA standard; 100 kA high fault with Class J fuses. Pilot duty: C600 (AC), R300 (DC). Size: 45 x 69.79 x 82.5 mm (W x H x D). Approvals: cULus Listed, CE. It operates from -25 to +60 °C and stores from -40 to +70 °C.
| Category | |
| Manufacturer | ATC Diversified |
| Part Status | Discontinued |
